Description
3 Axle 20Ft Skeleton Trailer is intended for container transfer and intermodal logistics. A skeletal frame supports the container at its designed mounting points while keeping the load platform open.
Where this trailer fits
- Match container length and corner-casting positions to the actual twist-lock layout.
- Check laden container mass, chassis axle loading and tractor coupling height.
- Plan access to lifting equipment and verify the locking sequence before dispatch.
Technical specification
Manufacturer-listed configuration for this model. Dimensions and component selections should be read together with the confirmed order drawing.
| Dimensions | 7500 × 2500 × 1000mm |
|---|---|
| Gross capacity | ≤60T |
| Main beam height | 500 mm (upper wing plate: 14 mm, lower wing plate: 16 mm) |
| Axles | 3 axles, 13T/16T |
| Tire size | 8 units, 12.00R22.5 |
| Suspension | Mechanical / Air suspension (optional) |
| Drawbars | 50# or 90# (optional) |
| Outriggers | 28T dual-speed |
| Rim | 9.00-22.5 or 9.75-22.5 |
| Painting | Sandblasting, electrostatic paint, and high-temperature curing |
Selection checklist
- Container size and loaded mass
- Twist-lock positions and locking hardware
- Kingpin size and fifth-wheel height
- Brake, electrical and air connections
- Route and terminal access
Buying and ownership questions
What configuration does this listing describe?
The technical table reproduces the manufacturer-listed equipment for this model. Where alternative components or sizes are listed, the order specification must identify the selected option.
How should I assess the working load?
Match the actual load to the documented trailer rating, axle and tire limits, tractor capability and route requirements. A supplier capacity figure alone does not establish the permitted road payload.
What information is needed to select the right version?
Provide container size and loaded mass, twist-lock positions and locking hardware, kingpin size and fifth-wheel height, together with the delivery ZIP code and the intended operating route. This allows the configuration and delivery plan to be checked against the job.
What is included with delivery?
The confirmed order identifies the trailer specification, supplied accessories and delivery scope. Delivery charges and eligibility follow the company shipping policy; do not assume an optional pump, compressor, hydraulic kit or other accessory is included unless specified.
What should I check for US use?
Verify the model-specific identification and certification documents, import eligibility and registration requirements before ordering for US road use. Published supplier specifications do not establish US approval.
Delivery and support
Contact Lenova Group with reference LNV-TRL-006 and your delivery location. Review the shipping policy, warranty policy and returns policy for the terms that apply to your order.
Technical reference: manufacturer model specification. The listed figures are supplier data; confirm the final configuration and documentation for the intended application.
