Description
3-Axle Fence Drawbar Trailer is intended for drawbar-connected freight and equipment operations. A drawbar connection requires a compatible towing vehicle and a planned coupling and braking arrangement.
Where this trailer fits
- Check hitch type, eye or coupling size and the towing vehicle rating.
- Confirm braking, electrical and air connections.
- Assess turning clearance, drawbar swing and load placement.
Technical specification
Manufacturer-listed configuration for this model. Dimensions and component selections should be read together with the confirmed order drawing.
| Product Name | 3-Axle Fence Drawbar Trailer |
|---|---|
| Rated Payload | 60000KG |
| Box Dimensions | 13000*2550*3600 mm |
| Main Beam | Top flange 14mm, bottom flange 16mm, web plate 8mm |
| Axles | 3 ×16T |
| Tires | 12× 12R22.5 |
| Wheel Rims | 12 × 9.0, 16mm |
| Leaf Springs | 10×90mm×13mm |
| Landing Gear | 28T |
| Kingpin | 90# JOST |
| Brake Valve | WABCO |
| Suspension | Mechanical suspension |
Selection checklist
- Tow vehicle and coupling specification
- Drawbar dimensions and connection height
- Brake and electrical interfaces
- Cargo and axle loading
- Turning and reversing space
Buying and ownership questions
What configuration does this listing describe?
The technical table reproduces the manufacturer-listed equipment for this model. Where alternative components or sizes are listed, the order specification must identify the selected option.
How should I assess the working load?
The manufacturer lists 60000KG. Match the actual load to the documented trailer rating, axle and tire limits, tractor capability and route requirements. A supplier capacity figure alone does not establish the permitted road payload.
What information is needed to select the right version?
Provide tow vehicle and coupling specification, drawbar dimensions and connection height, brake and electrical interfaces, together with the delivery ZIP code and the intended operating route. This allows the configuration and delivery plan to be checked against the job.
What is included with delivery?
The confirmed order identifies the trailer specification, supplied accessories and delivery scope. Delivery charges and eligibility follow the company shipping policy; do not assume an optional pump, compressor, hydraulic kit or other accessory is included unless specified.
What should I check for US use?
Verify the model-specific identification and certification documents, import eligibility and registration requirements before ordering for US road use. Published supplier specifications do not establish US approval.
Delivery and support
Contact Lenova Group with reference LNV-TRL-065 and your delivery location. Review the shipping policy, warranty policy and returns policy for the terms that apply to your order.
Technical reference: manufacturer model specification. The listed figures are supplier data; confirm the final configuration and documentation for the intended application.
