Description
4-Axle Flatbed Semi-Trailer is intended for general freight, long loads and container-compatible transport. An open deck gives flexible access for cranes, forklifts and load restraint systems.
Where this trailer fits
- Compare usable deck length and width with the longest item carried.
- Check concentrated load positions rather than relying only on the total capacity figure.
- Specify rated anchor points and an appropriate loading and restraint plan.
Technical specification
Manufacturer-listed configuration for this model. Dimensions and component selections should be read together with the confirmed order drawing.
| Product Name | 4-Axle Flatbed Semi-Trailer |
|---|---|
| Rated Payload | 55000KG |
| Box Dimensions | 12500*2500*1550 mm |
| Main Beam | Top flange 12mm, bottom flange 14mm, web plate 8mm |
| Axles | 4 ×16T |
| Tires | 16 × 12R22.5 tubeless tires |
| Wheel Rims | 12 × 9.0, 16mm |
| Leaf Springs | 10×90mm×13mm |
| Landing Gear | 28T |
| Kingpin | 90# JOST |
| Brake Valve | WABCO |
| Suspension | Mechanical suspension/Air suspension |
Selection checklist
- Cargo dimensions and point loads
- Deck material and working height
- Lashing points and restraint equipment
- Loading equipment and access
- Container locks where required
Buying and ownership questions
What configuration does this listing describe?
The technical table reproduces the manufacturer-listed equipment for this model. Where alternative components or sizes are listed, the order specification must identify the selected option.
How should I assess the working load?
The manufacturer lists 55000KG. Match the actual load to the documented trailer rating, axle and tire limits, tractor capability and route requirements. A supplier capacity figure alone does not establish the permitted road payload.
What information is needed to select the right version?
Provide cargo dimensions and point loads, deck material and working height, lashing points and restraint equipment, together with the delivery ZIP code and the intended operating route. This allows the configuration and delivery plan to be checked against the job.
What is included with delivery?
The confirmed order identifies the trailer specification, supplied accessories and delivery scope. Delivery charges and eligibility follow the company shipping policy; do not assume an optional pump, compressor, hydraulic kit or other accessory is included unless specified.
What should I check for US use?
Verify the model-specific identification and certification documents, import eligibility and registration requirements before ordering for US road use. Published supplier specifications do not establish US approval.
Delivery and support
Contact Lenova Group with reference LNV-TRL-045 and your delivery location. Review the shipping policy, warranty policy and returns policy for the terms that apply to your order.
Technical reference: manufacturer model specification. The listed figures are supplier data; confirm the final configuration and documentation for the intended application.
