Description
45m³ 4-Axle Rear Tipper with Lift Axle is intended for aggregates and suitable bulk materials for controlled tipping. A tipping body supports unloading through its specified hydraulic and gate arrangement.
Where this trailer fits
- Use material density and body volume to assess a suitable working load.
- Confirm tipping direction, tailgate operation and hydraulic connection requirements.
- Plan unloading on suitable ground with adequate overhead and side clearance.
Technical specification
Manufacturer-listed configuration for this model. Dimensions and component selections should be read together with the confirmed order drawing.
| Product Name | 4-Axle Rear Tipper Semi-Trailer with Lift Axle |
|---|---|
| Dump Body Dimensions | 9,000 × 2,500 × 2,000 mm (L × W × H) |
| Main Beam | Top Flange: 16 mm; Bottom Flange: 16 mm; Web Plate: 8 mm |
| Dump Body Plate Thickness | Floor: 8 mm; Side Walls: 6 mm |
| Hydraulic Cylinder | HYVA |
| Axles | 4 × 16T FUWA |
| Tires | 16 × 315/80 R22.5 |
| Wheel Rims | 12 × 9.0, 16 mm |
| Landing Gear | 28T JOST |
| Kingpin | JOST |
| Brake Valve | WABCO |
| Suspension | Liftable First Axle; Mechanical Suspension on the Rear Three Axles |
| Leaf Springs | 10 × 90 mm × 16 mm |
Selection checklist
- Material type and density
- Body volume and construction
- Hydraulic supply and tipping arrangement
- Tailgate or side-door operation
- Unloading surface and clearance
Buying and ownership questions
What configuration does this listing describe?
The technical table reproduces the manufacturer-listed equipment for this model. Where alternative components or sizes are listed, the order specification must identify the selected option.
How should I assess the working load?
Match the actual load to the documented trailer rating, axle and tire limits, tractor capability and route requirements. A supplier capacity figure alone does not establish the permitted road payload.
What information is needed to select the right version?
Provide material type and density, body volume and construction, hydraulic supply and tipping arrangement, together with the delivery ZIP code and the intended operating route. This allows the configuration and delivery plan to be checked against the job.
What is included with delivery?
The confirmed order identifies the trailer specification, supplied accessories and delivery scope. Delivery charges and eligibility follow the company shipping policy; do not assume an optional pump, compressor, hydraulic kit or other accessory is included unless specified.
What should I check for US use?
Verify the model-specific identification and certification documents, import eligibility and registration requirements before ordering for US road use. Published supplier specifications do not establish US approval.
Delivery and support
Contact Lenova Group with reference LNV-TRL-034 and your delivery location. Review the shipping policy, warranty policy and returns policy for the terms that apply to your order.
Technical reference: manufacturer model specification. The listed figures are supplier data; confirm the final configuration and documentation for the intended application.
